Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-1752
• KIT: ACCUMULATORS/DRIERS: 207-2017
• KIT: EXP VALVES/ORIF TUBE: 208-7317
• {EXP VALVES/ORIF TUBE}: Tube Outside Diameter: 10.8
• {COMPRESSORS}: Discharge Port (mm): 12
• {COMPRESSORS}: Voltage: 12
• {EXP VALVES/ORIF TUBE}: Screen Micron Rating: 120
• {COMPRESSORS}: Pulley Diameter (mm): 125
• {COMPRESSORS}: Suction Port (mm): 14.5
• {COMPRESSORS}: Gauge Line (mm): 40
• {COMPRESSORS}: Grooves: 6
• {EXP VALVES/ORIF TUBE}: Inner Diameter (mm): 7.5
• {EXP VALVES/ORIF TUBE}: Length (mm): 89.4
• {EXP VALVES/ORIF TUBE}: Diameter (mm): 9.8
• {ACCUMULATORS/DRIERS}: Stud Thread Size: M8 x 1.25
• {COMPRESSORS}: Control Valve (Y/ N): N
• {EXP VALVES/ORIF TUBE}: Material Type: plastic/ cloth
• {EXP VALVES/ORIF TUBE}: Refrigerant Type: R-134A
• {EXP VALVES/ORIF TUBE}: Color: Red
• {COMPRESSORS}: Compressor Type: SD7H15
• {COMPRESSORS}: Diode (Y/ N): Y
