Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-1102
• KIT: HOSE/TUBE ASSY (+ACCUM-DRIER): 207-1098
• KIT: EXP VALVES/ORIF TUBE: 208-291-1
• {EXP VALVES/ORIF TUBE}: Screen Micron Rating: 100 mesh
• {EXP VALVES/ORIF TUBE}: Length (mm): 102
• {COMPRESSORS}: Voltage: 12
• {COMPRESSORS}: Pulley Diameter (mm): 132
• {HOSE/TUBE ASSY (+ACCUM-DRIER)}: Length (mm): 229
• {COMPRESSORS}: Grooves: 4
• {HOSE/TUBE ASSY (+ACCUM-DRIER)}: Inlet Fitting: 5/8 Male Springlock
• {EXP VALVES/ORIF TUBE}: Inner Diameter (mm): 6.2
• {HOSE/TUBE ASSY (+ACCUM-DRIER)}: Outer Diameter (m: 89
• {EXP VALVES/ORIF TUBE}: Diameter (mm): 9.8
• {EXP VALVES/ORIF TUBE}: Tube Outside Diameter: 9.8
• {EXP VALVES/ORIF TUBE}: Color: Black
• {COMPRESSORS}: Compressor Type: FS10
• {COMPRESSORS}: Control Valve (Y/ N): N
• {EXP VALVES/ORIF TUBE}: Material Type: Plastic
• {COMPRESSORS}: Compressor Mount: Tangent
• {HOSE/TUBE ASSY (+ACCUM-DRIER)}: Service Port (Y/ : Y
