Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-1100
• KIT: ACCUMULATORS/DRIERS: 207-1062
• KIT: EXP VALVES/ORIF TUBE: 208-291-1
• {EXP VALVES/ORIF TUBE}: Screen Micron Rating: 100 mesh
• {EXP VALVES/ORIF TUBE}: Length (mm): 102
• {COMPRESSORS}: Pulley Diameter (mm): 114
• {COMPRESSORS}: Voltage: 12
• {ACCUMULATORS/DRIERS}: Inlet Fitting Diameter: 17.9
• {ACCUMULATORS/DRIERS}: Outlet Fitting Diameter: 19.6
• {ACCUMULATORS/DRIERS}: Body Length: 223
• {COMPRESSORS}: Belt Width (mm): 25
• {EXP VALVES/ORIF TUBE}: Inner Diameter (mm): 6.2
• {COMPRESSORS}: Grooves: 8
• {ACCUMULATORS/DRIERS}: Body Diameter: 88
• {EXP VALVES/ORIF TUBE}: Diameter (mm): 9.8
• {EXP VALVES/ORIF TUBE}: Tube Outside Diameter: 9.8
• {EXP VALVES/ORIF TUBE}: Color: Black
• {ACCUMULATORS/DRIERS}: Inlet Fitting Type: Female
• {ACCUMULATORS/DRIERS}: Outlet Fitting Type: Female
• {COMPRESSORS}: Compressor Type: FS10
• {ACCUMULATORS/DRIERS}: Sight Glass (Y/ N): N
• {ACCUMULATORS/DRIERS}: Mounting Bracket Included: No
• {EXP VALVES/ORIF TUBE}: Material Type: Plastic
• {COMPRESSORS}: Compressor Mount: Tangent
