Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-1496
• KIT: ACCUMULATORS/DRIERS: 207-924
• KIT: EXP VALVES/ORIF TUBE: 208-706-1
• {ACCUMULATORS/DRIERS}: Inlet Fitting Diameter
• {ACCUMULATORS/DRIERS}: Outlet Fitting Diameter
• {ACCUMULATORS/DRIERS}: Mount Type
• {COMPRESSORS}: Connector Quantity: 1
• {EXP VALVES/ORIF TUBE}: Tube Outside Diameter: 1.8
• {COMPRESSORS}: Clutch Maximum Diameter: 105
• {COMPRESSORS}: Distance Between Mounting Holes: 112
• {COMPRESSORS}: Coil Clock Position: 12
• {COMPRESSORS}: Coil Voltage: 12
• {COMPRESSORS}: Pulley Ridge Diameter: 130
• {COMPRESSORS}: Pulley Outside Diameter: 134
• {COMPRESSORS}: Discharge Port Inside Diameter: 16.4
• {ACCUMULATORS/DRIERS}: Body Length: 205
• {COMPRESSORS}: Suction Port Inside Diameter: 30.6
• {COMPRESSORS}: Pulley Groove Quantity: 6
• {COMPRESSORS}: Mounting Hole Quantity: 8
• {ACCUMULATORS/DRIERS}: Body Diameter: 89
• {ACCUMULATORS/DRIERS}: Type: DRIER
• {ACCUMULATORS/DRIERS}: Inlet Fitting Type: Female
• {ACCUMULATORS/DRIERS}: Outlet Fitting Type: Female
• {COMPRESSORS}: Hub Type: Leaf Spring
• {COMPRESSORS}: Connector Gender: Male
• {ACCUMULATORS/DRIERS}: Sight Glass (Y/ N): N
• {ACCUMULATORS/DRIERS}: Mounting Bracket Included: No
• {ACCUMULATORS/DRIERS}: Switch Service Port: No
• {COMPRESSORS}: Compatible Refrigerant Oil Type: pag46
• {EXP VALVES/ORIF TUBE}: Material Type: Plastic
• {COMPRESSORS}: Refrigerant Type: R134A
• {COMPRESSORS}: Connector Shape: Rectangle
• {COMPRESSORS}: Compressor Type: SD7H15
• {COMPRESSORS}: Pulley Belt Type: Serpentine
• {COMPRESSORS}: Mounting Type: Tangent
• {COMPRESSORS}: Clutch Included: Yes
• {COMPRESSORS}: Oil Filled: Yes
