Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-1763
• KIT: ACCUMULATORS/DRIERS: 207-5033
• KIT: EXP VALVES/ORIF TUBE: 208-6112
• KIT: EXP VALVES/ORIF TUBE: 208-6569
• {COMPRESSORS}: Mounting Flange Thickness
• {COMPRESSORS}: Pulley Lip Diameter
• {COMPRESSORS}: Switch Type
• {EXP VALVES/ORIF TUBE}: Tonnage: 1
• {COMPRESSORS}: Connector Quantity: 1
• {EXP VALVES/ORIF TUBE}: Superheat: 10
• {COMPRESSORS}: Clutch Maximum Diameter: 109.8
• {COMPRESSORS}: Pulley Ridge Diameter: 119
• {COMPRESSORS}: Coil Clock Position: 12
• {COMPRESSORS}: Coil Voltage: 12
• {COMPRESSORS}: Casing Outside Diameter: 120
• {COMPRESSORS}: Pulley Outside Diameter: 123
• {COMPRESSORS}: Discharge Port Inside Diameter: 16.5
• {COMPRESSORS}: Suction Port Inside Diameter: 16.5
• {COMPRESSORS}: Terminal Qty: 2
• {COMPRESSORS}: Wire Qty: 2
• {EXP VALVES/ORIF TUBE}: Superheat: 2.5
• {COMPRESSORS}: Wire Gauge Measurement: 220
• {ACCUMULATORS/DRIERS}: Height (mm): 257
• {ACCUMULATORS/DRIERS}: Diameter (mm): 76
• {COMPRESSORS}: Mounting Hole Quantity: 8
• {COMPRESSORS}: Pulley Groove Quantity: 8
• {ACCUMULATORS/DRIERS}: Inlet (mm): 8.5
• {ACCUMULATORS/DRIERS}: Outlet (mm): 8.5
• {COMPRESSORS}: Distance From Clutch To Mounting Fl: 82
• {COMPRESSORS}: Distance Between Mounting Holes: 87
• {COMPRESSORS}: Rotation: CW
• {COMPRESSORS}: Hub Type: Leaf Spring
• {COMPRESSORS}: Connector Gender: Male
• {ACCUMULATORS/DRIERS}: Sight Glass (Y/ N): N
• {COMPRESSORS}: Switch Included: No
• {COMPRESSORS}: Thermal Or Non Thermal: non thermal
• {COMPRESSORS}: Connector Shape: Oval
• {COMPRESSORS}: Compatible Refrigerant Oil Type: PS-R1
• {EXP VALVES/ORIF TUBE}: Refrigerant: R134A
• {COMPRESSORS}: Refrigerant Type: R134A
• {COMPRESSORS}: Compressor Type: SD7H15
• {COMPRESSORS}: Pulley Belt Type: Serpentine
• {COMPRESSORS}: Terminal Type: Spade
• {COMPRESSORS}: Mounting Type: Tangent
• {COMPRESSORS}: Clutch Included: Yes
• {COMPRESSORS}: Oil Filled: Yes
• {COMPRESSORS}: Switch Service Port: Yes
