Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-1146
• KIT: ACCUMULATORS/DRIERS: 207-1054
• KIT: EXP VALVES/ORIF TUBE: 208-291-1
• {COMPRESSORS}: Connector Quantity: 1
• {COMPRESSORS}: Coil Clock Position: 10
• {EXP VALVES/ORIF TUBE}: Screen Micron Rating: 100 mesh
• {EXP VALVES/ORIF TUBE}: Length (mm): 102
• {COMPRESSORS}: Clutch Maximum Diameter: 105
• {COMPRESSORS}: Pulley Ridge Diameter: 110
• {COMPRESSORS}: Pulley Outside Diameter: 115
• {COMPRESSORS}: Coil Voltage: 12
• {COMPRESSORS}: Mounting Flange Thickness: 12
• {COMPRESSORS}: Distance Between Mounting Holes: 126
• {COMPRESSORS}: Discharge Port Inside Diameter: 16
• {COMPRESSORS}: Casing Outside Diameter: 161.5
• {COMPRESSORS}: Terminal Qty: 2
• {COMPRESSORS}: Wire Qty: 2
• {ACCUMULATORS/DRIERS}: Length (mm): 225
• {COMPRESSORS}: Suction Port Inside Diameter: 30.6
• {COMPRESSORS}: Pulley Groove Quantity: 4
• {EXP VALVES/ORIF TUBE}: Inner Diameter (mm): 6.2
• {COMPRESSORS}: Mounting Hole Quantity: 7
• {EXP VALVES/ORIF TUBE}: Diameter (mm): 9.8
• {EXP VALVES/ORIF TUBE}: Tube Outside Diameter: 9.8
• {EXP VALVES/ORIF TUBE}: Color: Black
• {COMPRESSORS}: Terminal Type: blade
• {COMPRESSORS}: Hub Type: DENSO
• {COMPRESSORS}: Connector Gender: Female
• {COMPRESSORS}: Compressor Type: HU6
• {COMPRESSORS}: Switch Included: No
• {COMPRESSORS}: Switch Service Port: No
• {COMPRESSORS}: Connector Shape: Oval
• {EXP VALVES/ORIF TUBE}: Material Type: Plastic
• {COMPRESSORS}: Refrigerant Type: R134A
• {COMPRESSORS}: Pulley Belt Type: Serpentine
• {COMPRESSORS}: Clutch Included: Yes
• {COMPRESSORS}: Oil Filled: Yes
