Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-7260
• KIT: ACCUMULATORS/DRIERS: 207-1274
• KIT: EXP VALVES/ORIF TUBE: 208-548
• {ACCUMULATORS/DRIERS}: Fuse Plug (Y/ N)
• {ACCUMULATORS/DRIERS}: Pad Mount
• {EXP VALVES/ORIF TUBE}: Liquid Outlet Fitting Thre: 11.8
• {COMPRESSORS}: Clocking: 12
• {COMPRESSORS}: Voltage: 12
• {ACCUMULATORS/DRIERS}: Inlet Fitting Diameter: 12.3
• {COMPRESSORS}: Pulley Diameter (mm): 120
• {EXP VALVES/ORIF TUBE}: Liquid Inlet Fitting Threa: 13.8
• {EXP VALVES/ORIF TUBE}: Suction Inlet Fitting Thre: 14.6
• {COMPRESSORS}: Discharge Port (mm): 16.6
• {COMPRESSORS}: Suction Port (mm): 18
• {EXP VALVES/ORIF TUBE}: Suction Outlet Fitting Thr: 18
• {ACCUMULATORS/DRIERS}: Body Diameter: 30
• {ACCUMULATORS/DRIERS}: Body Length: 342
• {EXP VALVES/ORIF TUBE}: Width (mm): 39.5
• {EXP VALVES/ORIF TUBE}: Mounting Hole Quantity: 4
• {COMPRESSORS}: Gauge Line (mm): 46
• {COMPRESSORS}: Grooves: 6
• {EXP VALVES/ORIF TUBE}: Length (mm): 84
• {ACCUMULATORS/DRIERS}: Material Type: Aluminum
• {EXP VALVES/ORIF TUBE}: Material Type: Aluminum
• {EXP VALVES/ORIF TUBE}: Type: Block
• {ACCUMULATORS/DRIERS}: In Line Filter Material: cloth
• {ACCUMULATORS/DRIERS}: Type: DRIER
• {COMPRESSORS}: Compressor Mount: Ear
• {EXP VALVES/ORIF TUBE}: Liquid Inlet Fitting Gende: Female
• {EXP VALVES/ORIF TUBE}: Liquid Outlet Fitting Gend: Female
• {EXP VALVES/ORIF TUBE}: Suction Inlet Fitting Gend: Female
• {EXP VALVES/ORIF TUBE}: Suction Outlet Fitting Gen: Female
• {ACCUMULATORS/DRIERS}: Inlet Fitting Type: Female
• {ACCUMULATORS/DRIERS}: Outlet Fitting Type: Female
• {ACCUMULATORS/DRIERS}: Inlet Filter Fitting Thread: M5X0.8
• {EXP VALVES/ORIF TUBE}: Mounting Hole Diameter: M8
• {ACCUMULATORS/DRIERS}: Inlet Filter Fitting Type: Male
• {ACCUMULATORS/DRIERS}: Port Gender: Male
• {COMPRESSORS}: Diode (Y/ N): N
• {ACCUMULATORS/DRIERS}: Desiccant Replaceable: No
• {ACCUMULATORS/DRIERS}: Moisture Indicator Window: No
• {ACCUMULATORS/DRIERS}: Mounting Bracket Included: No
• {EXP VALVES/ORIF TUBE}: Refrigerant Type: R134A
• {COMPRESSORS}: Compressor Type: SD7V16
• {EXP VALVES/ORIF TUBE}: Color: Silver
• {COMPRESSORS}: Control Valve (Y/ N): Y
• {ACCUMULATORS/DRIERS}: Desiccant: Yes
