Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-14376
• KIT: ACCUMULATORS/DRIERS: 207-1268
• KIT: EXP VALVES/ORIF TUBE: 208-5093
• {COMPRESSORS}: Voltage: 12
• {COMPRESSORS}: Pulley Diameter (mm): 120
• {EXP VALVES/ORIF TUBE}: Liquid Outlet (mm): 15
• {EXP VALVES/ORIF TUBE}: Suction Inlet (mm): 15
• {EXP VALVES/ORIF TUBE}: Suction Outlet (mm): 15
• {COMPRESSORS}: Discharge Port (mm): 17
• {EXP VALVES/ORIF TUBE}: Superheat: 2.5
• {ACCUMULATORS/DRIERS}: Core Thickness: 20
• {ACCUMULATORS/DRIERS}: Outside Diameter: 20
• {COMPRESSORS}: Suction Port (mm): 23
• {COMPRESSORS}: Grooves: 6
• {EXP VALVES/ORIF TUBE}: Liquid Inlet (mm): 7.5
• {COMPRESSORS}: Gauge Line (mm): 91.5
• {ACCUMULATORS/DRIERS}: Material Type: cloth
• {ACCUMULATORS/DRIERS}: Gasket Or Seal Included: No
• {ACCUMULATORS/DRIERS}: Wiring Harness Included: No
• {COMPRESSORS}: Refrigerant: R134a or R1234yf
• {ACCUMULATORS/DRIERS}: Universal Or Specific Fit: UNIVERSAL
• {COMPRESSORS}: Compressor Type: VS18E
• {ACCUMULATORS/DRIERS}: Color: white
• {COMPRESSORS}: Control Valve (Y/ N): Y
